| The D-SG series PFA nitrogen gas gun is developed specifically for high-purity semiconductor applications. |  |
| PartNo. | Tube
O.D. |
Orifice | A | B | C | D
(Max) |
HEX1 | HEX2 | MinimuPanel HoleDiameter |
| D-G1-SPM4-4-FA | 1/4 | 3.8 | 85.5 | 43.9 | 24.7 | 12.7 | 19.4 | 16.3 | 1/2 |
| D-G1-SPM6-6-FA | 3/8 | 6.3 | 90.5 | 46.5 | 26.7 | 12.7 | 21.8 | 20 | 5/8° |
| D-G1-SPM8-8-FA | 1/2″ | 9.6 | 96 | 49.2 | 28.9 | 12.7 | 23.3 | 23.8 | 3/4° |
| D-G1-SPM12-12-FA | 3/4 | 16 | 103.5 | 52.5 | 33 | 12.7 | 33.3 | 30.1 | 1″ |
| D-G1-SPM16-16-FA | 1° | 22.3 | 117 | 56.2 | 37.2 | 12.7 | 44.4 | 41.2 | 1-7/16° |
