Specification
| Item | Liquid Extraction Fitting (Small Drum Type) |
| Working Pressure bar | 0.7~3.4 |
| Maximum Temperature ℃ | -18~200 |
| Material | PTFE、PFA |
| Liquid End Connection | ¼” ,⅜” ,½” ,¾” ,1″ |
| Gas End Connection | ¼” ,⅜” ,½” ,¾” ,1″ |
| Connection Type | Thread、Flared、Sleeve Type、Ferrule |
Features
- Excellent sealing performance ensures leak-proof liquid dispensing.
- Tool-free installation – simply screw the fitting onto the container for quick assembly.
- Innovative low-residual design minimizes liquid retention.
