Drawer body and panel, steel door with internal steel plate, furniture front and rear sealing plate, shelf, top sealing plate -1.0mm Steel plates for the upper, rear, bottom, and base of the steel cabinet, steel cabinet back plate, component fastening plate, glass door frame steel plate, vertical village plate, steel door outer steel plate, and manhole sealing plate -1.2mm Steel cabinet upper support components, connecting baffles, angle brackets, feet, brackets, foot connectors, and extension frames -1.5mm Drawer slide rail, door and cabinet hinge reinforcement, and L-shaped front foot support plate -1.6mm

Metallizing

Preprocessing: Process according to standard procedures based on the type of steel plate.

Spraying: Epoxy resin powder electrostatic spraying, fixed to a smooth surface in a high-temperature oven, without any peeling, bubbling, indentation, surface scratches, pitting, cracks, chipping, or cutting edges on the sprayed layer; Cutting, drilling, and side corners should be deburred.

Spray thickness: Spray epoxy resin powder with a thickness of not less than 75 μ m, which should meet SEFA standards. The color can be selected and determined by the user according to the standard color card.

The surface treatment performance requirements should comply with the SEFA 8M standard, and the cabinet should be a fully steel floor standing structure that can be used alone or in combination. The side panel and back panel of the cabinet are designed to form a circular shape, with smooth transitions in both vertical and horizontal directions, without overlapping or cracking. The entire cabinet door and drawer panel are on the same plane, and there is soundproofing material inside the panel.

Cabinet size

Dimensions: Length, width, height with an error margin of 3mm; Verticality of adjacent edges: Diagonal of countertop, diagonal of frame 1000mm ≤ 3mm; 2000mm≤4mm; 3000mm≤5mm,

Instrument and control panel cabinets; The height is 901mm (35% inches); The depth of the cabinet is 559mm (22 *); Length 457mm (18 °), 610mm (24 “), 762mm (30”), 914mm (36 “), 1016mm (407, 1067mm (42”), 1219mm (48 “), arranged according to the size of the laboratory space.

All bottom cabinets have four adjustable screw supports, which can be adjusted for level and height using specialized tools, with a maximum adjustment of 30mm. The back panel of the cabinet door can be easily disassembled with simple tools to inspect the piping system

The outer side of the laboratory countertop is rounded with an R-angle arc, and a water stop groove is opened below the front edge of the countertop to effectively prevent accumulated water from flowing into the cabinet along the edge of the countertop. (Optional: The edge water blocking strip is made of the same material as the tabletop, with a height of 100mm and rounded outer edges).
